CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 244 of 350
DUT1(config)# mpls ilm-entry php
310 13.13.13.1 Configure one static ILM
entry.
DUT1(config)# mpls ilm-entry php
320 12.12.12.2 Configure one static ILM
entry.
29.1.4 Validation Commands
Use the show mpls vpls and the show mpls vpls mesh commands respectively to display
complete information about the VPLS. The following are the sample outputs for the show
commands displaying VPLS.
1) PE1
DUT1#show mpls vpls vpls1
Virtual Private LAN Service Instance: vpls1, ID: 1
Group ID: 0, VPLS Type: Ethernet, Configured MTU: 0
Description: none
Configured interfaces: eth-0-1 eth-0-2
Mesh Peers: 14.14.14.2 (Up)
11.11.11.3 (Up)
DUT1#show mpls vpls mesh
VPLS-ID Peer Addr In-Label Out-Intf Out-Label Type Lkps/St
1 14.14.14.2 102 eth-0-4 201 RAW 1/Up
1 11.11.11.3 103 eth-0-3 301 RAW 1/Up
