CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 166 of 350
to delay when object state is turned
from down to up.
DUT(config-track)# delay
down 30 (Optional)Configure the track object
parameters:
specify a period of time (in seconds)
to delay when object state is turned
from up to down.
DUT(config-track)#exit Exit the track mode.
DUT(config)#exit Exit the Configure mode.
Validation Commands
To display the track rtr state configuration, use the show track privileged EXEC
command.
DUT#show track
Track 1
Type : Response Time Reporter(RTR) State
RTR entry number : 1
State : up
Delay up : 30 seconds
Delay down : 30 seconds
21.3 Configuring VRRP TRACK
Beginning in privileged EXEC mode, follow these steps to configure the vrrp track:
Command Description
DUT#configure terminal Enter the Configure mode.
DUT(config)# router vrrp 1 Create a new VRRP session on the router and
specify the VRID for the session.
DUT(config-router)# track 1
30 Track an object in vrrp process, object
id is 1, Priority delta is 30.
DUT(config-router)#exit Exit the router mode.
DUT(config)#exit Exit the Configure mode.
Validation Commands
To display the vrrp track configuration, use the show vrrp privileged EXEC
command.
DUT#show vrrp
VRID <1>
