CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 214 of 350
DUT1#show ldp session
Peer IP Address IF Name My Role State KeepAlive
11.11.17.2 eth-0-9 Passive OPERATIONAL 30
26.1.2 Configure a new FEC to set up a LSP between lsr-a, lsr-b and lsr-c.
configure lsr-c:
Command Description
DUT1#configure terminal Enter the Configure mode.
DUT1(config)#router rip Enter the router-rip mode
DUT1(config-router)# redistribute
static Redistribute static routes to
RIP with default metric.
DUT1(config-router)#exit Exit the router-rip mode
DUT1(config)#ip route 5.5.5.0/24
11.11.10.1 Configuring a static ip route
entry.
DUT1(config)#interface eth-0-10 Enter the Interface mode.
• eth-0-10—Specify the
interface
DUT1(config-if)#no switchport Configuring the port as layer 3
port.
DUT1(config-if)#ip address
11.11.10.2/24 Create IP address on the port.
Validation Commands
To display the LDP configuration, use the show mpls forwarding-table privileged
EXEC command.
1) show result on lsr-a:
DUT1# show mpls ftn-forwarding
FEC Out-Label Nexthop Out-Intf
5.5.5.0/24 1024 11.11.17.2 eth-0-17
11.11.9.0/24 3 11.11.17.2 eth-0-17
11.11.10.0/24 1027 11.11.17.2 eth-0-17
2) show result on lsr-b
DUT1# show mpls ilm-forwarding
FEC I/O Label Nexthop Out-Intf
5.5.5.0/24 1024/1024 11.11.9.2 eth-0-9
11.11.10.0/24 1027/3 11.11.9.2 eth-0-9
