CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 232 of 350
DUT1(config)#exit Exit the Interface mode.
DUT1(config)# router ldp Enter the router-ldp mode.
DUT1(config-router)#
targeted-peer 11.11.3.3 Configure Targeted Peer.
DUT1(config-router)#
targeted-peer 11.11.4.4 Configure Targeted Peer.
DUT1(config-router)#
transport-address 11.11.1.1 Configure the transport address for
a label space.
DUT1(config-router)#exit Exit the router-ldp mode.
DUT1(config)#router rip Enter the router-rip mode
DUT1(config-router)#network
11.11.1.1/16 Associate networks with the RIP
process.
DUT1(config-router)#exit Exit the router-rip mode
DUT1(config)#mpls vpls-vlan
4000 4010 Create a block of continuous vlan id
which used for vpls function.
DUT1(config)#mpls vpls v1 100 Create a VPLS instance and come
into the VPLS instance mode.
DUT1(config-vpls)#vpls-peer
11.11.3.3 raw Add a PE for VPLS instance.
DUT1(config-vpls)#vpls-peer
11.11.4.4 raw Add a PE for VPLS instance.
DUT1(config-vpls)#exit Exit VPLS instance mode.
DUT1(config)#interface eth-0-1 Enter the Interface mode.
• eth-0-1—Specify the interface
DUT1(config-if)#mpls-vpls v1 Bind an interface to a VPLS
instance.
DUT1(config-if)#exit Exit the Interface mode.
DUT1(config)#interface eth-0-2 Enter the Interface mode.
• eth-0-2—Specify the interface
DUT1(config-if)#mpls-vpls v1 Bind an interface to a VPLS
instance.
DUT1(config-if)#exit Exit the Interface mode.
