5.3.3 Validation Commands
Bridge 1
DUT#show interface switchport interface eth-0-1
Interface name : eth-0-1
Switchport mode : access
Ingress filter : enable
Acceptable frame types : vlan-untagged only
Default Vlan : 2
Configured Vlans : 2
DUT#show vlan brief
VLAN ID Name State STP ID DSCP Member ports
(u)-Untagged, (t)-Tagged
======= ================ ======= ======= ======= ========================
1 default ACTIVE 0 Disable eth-0-2(u) eth-0-3(u)
eth-0-4(u) eth-0-5(u)
eth-0-6(u) eth-0-7(u)
eth-0-8(u) eth-0-9(u)
eth-0-10(u) eth-0-11(u)
eth-0-12(u) eth-0-13(u)
eth-0-14(u) eth-0-15(u)
eth-0-16(u) eth-0-17(u)
eth-0-18(u) eth-0-19(u)
eth-0-20(u) eth-0-21(u)
eth-0-22(u) eth-0-23(u)
2 VLAN0002 ACTIVE 0 Disable eth-0-1(u)
5.4 Configuring Trunk Port
Trunk port receives tagged, untagged, and priority-tagged frames, and transmits both untagged
and tagged frames. If trunk port receives an untagged frame, this frame will be assigned to the
VLAN of the trunk port’s PVID; if a frame send out from the trunk port and the frame’s VID is
equal to the trunk port’s PVID, this frame will be send out without VLAN tag.
