CanogaOS Configuration Guide
Proprietary & Confidential Canoga Perkins Metro Ethernet Switches Page 150 of 350
the match conditions above are not
met. This is used to prevent routes to
be denied when not match the match
criteria above.
DUT(config-route-map)# exit Exit route-map mode and return to
configure mode.
DUT(config)# router ospf 100 Enter OSPF router mode.
DUT(config-router)#
redistribute rip route-map
abc Configure to apply the route-map on
the redistribute command in OSPF.
DUT(config-router)# end Exit the OSPF mode and return to the
privileged EXEC mode.
Validation Commands
To display the route-map configuration, use the show route-map [NAME] in the
privileged EXEC command.
DUT# show route-map
route-map abc, permit, sequence 10
Match clauses:
metric 20
Set clauses:
tag 2
route-map abc, permit, sequence 20
Match clauses:
Set clauses:
Configuring the route-map and applying the route-map to BGP policy routing
Beginning in privileged EXEC mode, follow these steps to configure the route-map:
Command Description
DUT1# configure terminal Enter the Configure mode.
DUT1(config)# ip access-list
acl1 Create an access-list named acl1.
DUT(config-ip-acl)# permit
any any 3.3.3.0 0.0.0.255 Create a rule to permit the route with
3.3.3.0/24
DUT1(config-ip-acl)# exit Exit the access-list configure mode
and return to configure mode.
DUT1(config)# route-map
abc permit Create a route-map named abc and
enter route-map mode.
DUT1(config-route-map)# Configure the match criteria.
