CO2 specifications (for additional information, refer to the directions for use that accompanies
each accessory)
Accuracy
0 to 70 breaths per minute: ±1 breath per minute
71 to 120 breaths per minute: ±2 breaths per minute
121 to 150 breaths per minute: ±3 breaths per minute
Resolution
1 breath per minute
1
The accuracy specification is maintained to within 4% of the values indicated in the presence of interfering gases in
accordance with ISO 21647, clauses 51.101.3 and 101.1.
2
The accuracy specification is maintained to within 4% of the values indicated in the presence of up to 80% helium
with up to 15% oxygen when tested in accordance with ISO 21647.
3
The accuracy specification is maintained when tested for drift in accordance with ISO 21647, clause 51.101.2.
EarlySense specifications
Sensor
Dimensions
300mm x 210mm x 2.5mm
Weight
160 g
Material
Polycarbonate + ABS
Connector
RS232 (S11M03-P04M500-5260(ODU))
Sensor power supply
Electrical absolute maximum current, DC in Minimum: –0.3V
Maximum: 5.5V
Operating current
Minimum: 4.9V
Typical: 5.0V
Maximum: 5.2V
Power consumption at 5V operating current Minimum: 1mA
Maximum: 4mA
Module
Dimensions
135mm x 75mm x 10mm
Weight
800 g
Host connection
USB Mini-B
Module power supply
Electrical absolute maximum current, DC in Minimum: –0.3V
Maximum: 5.5V
214 Specifications
