Fault

Code

Displayed

Message

Additional

Message

Further Steps and Checks

2.19

Open Lead

Check Terminal
xx

• Check for open lead.

2.20

Input Fault

Check Terminal
xx

Missing test pulses.

• Check for short to ground.

2.21

Open Lead

Check Terminal
xx

• Check for open lead.

2.22 –
2.23

Input Fault

Check Terminal
xx

• Check for unstable signal on the input.

2.24

Input Activated
While Bypassed

Perform System
Reset

A two-hand control input was activated (turned ON) while it was bypassed.

2.25

Input Fault

Monitoring

Timer Expired

Before AVM

Closed

After the associated Safety Output turned OFF, the AVM input did not close before its
AVM monitoring time expired.

• Either the AVM is disconnected, or its response to the Safety Output turning OFF

is too slow.

• Check the wiring to the AVM.
• Check the timing setting; increase the setting if necessary.
• Contact the factory.

2.26

Input Fault

AVM Not
Closed When
Output Turned
ON

The AVM input was open, but should have been closed, when the associated Safety
Output was commanded ON.

• The AVM may be disconnected; check the wiring to the AVM.

3.1

EDMxx Fault

Check Terminal
xx

EDM contact open prior to turning ON the Safety Outputs.

• Check for a stuck-ON contactor or relay.
• Check for open wire.

3.2

EDMxx Fault

Check Terminal
xx

EDM contact(s) failed to close within 250 ms after the Safety Outputs turned OFF.

• Check for slow or stuck-ON contactor or relay.
• Check for open wire.

3.3

EDMxx Fault

Check Terminal
xx

EDM contact(s) open prior to turning ON the Safety Outputs.

• Check for stuck-ON contactor or relay.
• Check for open wire.

3.4

EDMxx Fault

Check Terminal
xx

EDM contact pair mismatched for longer than 250 ms.

• Check for slow or stuck-ON contactor or relay.
• Check for open wire.

3.5

EDMxx Fault

Check Terminal
xx

• Check for unstable signal on the input.

3.6

EDMxx Fault

Check Terminal
xx

• Check for short to ground.

3.7

EDMxx Fault

Check Terminal
xx

• Check for short between inputs.
