Recovery Time (OFF to ON): 400 ms max. (with manual reset option)
Recovery Time (OFF to ON): 400 ms max. plus input debounce time (auto reset)

Onboard LCD Information Display—Password Requirements

Password is not required:
Run mode (I/O status)

Fault (I/O fault detection and remedial steps)

Review configuration parameters (I/O properties and terminals)
Password is required:
Configuration mode (create/modify/confirm/download configurations)

Environmental Rating

NEMA 1 (IEC IP20), for use inside NEMA 3 (IEC IP54) or better enclosure

Operating Conditions

Temperature range: 0° to +55° C (+32° to 131° F)

Mechanical Stress

Shock: 15g for 11 milliseconds, half sine, 18 shocks total (per IEC 61131-2)
Bump: 10g for 16 milliseconds, 6000 cycles total (per IEC 61496-1)
Vibration: 3.5 mm occasional / 1.75 mm continuous @ 5Hz to 9Hz, 1.0g occasional and 0.5g continuous @ 9Hz to 150Hz:
(per IEC 61131-2) and 0.35 mm single amplitude / 0.70 mm peak-to-peak @ 10 to 55Hz (per IEC 61496-1), all @ 10 sweep
cycles per axis

EMC

Meets or exceeds all EMC requirements in IEC 61131-2, IEC 61496-1 (Type 4), and IEC 62061 Annex E, Table E.1 (in-
creased immunity levels)

Removable Terminals

Screw terminals

Wire sizes: 16, 18, 20, 22 or 24 AWG (0.20 – 1.31 mm²)
Wire strip length: 5.00 mm (0.197")
Tightening torque: 0.23 Nm (2 in. lbs.) nominal; 0.34 Nm (3.0 in. lbs.) maximum

Clamp terminals

Important: Clamp terminals are designed for 1 wire only. If more than 1 wire is connected to a terminal, a wire could
loosen or become completely disconnected from the terminal, causing a short.
Wire size: 16, 18, 20, 22, or 24 AWG (0.20 – 1.31 mm²)
Wire strip length: 9.00 mm (0.35")

Network Interface (Model SC22-3E only)

Ethernet 10/100 Base-T/TX, RJ45 modular connector

Selectable auto negotiate or manual rate and duplex

Auto MDI/MDIX (auto cross)
Protocols: EtherNet/IP (with PCCC), Modbus/TCP
Data: 32 configurable virtual Status Outputs; fault diagnostic codes and messages; access to fault log

Product Performance Standards

IEC 62061 Safety of Machinery – Functional Safety of Safety-Related Electrical, Electronic and Programmable Electronic
Control Systems: SIL CL 3

IEC 61508 Functional Safety of Electrical/Electronic/Programmable Electronic Safety-Related Systems: SIL 3

ISO 13849-1 (1999): Category 4

SC22-3/-3E Safety Controller Instruction Manual

24

www.bannerengineering.com - tel: 763-544-3164

P/N 133487 rev. C
