background image

5.1.4 Other Functions

Receive a Configuration from the Safety Controller

To receive a configuration from a Controller and display it in the PCI:

• Connect the Safety Controller to the PC using the USB cable.
• Apply 24V dc power to the Controller.

Click on the Receive button

in the tool bar.

• If the configuration is not already confirmed, you may choose to confirm it at this time.

Send a Configuration to the Safety Controller

To send a configuration from the PCI to a Controller:

• Connect the Safety Controller to the PC, using the USB cable.
• Apply 24V dc power to the Controller.

Click on the Send button

in the tool bar.

Open a Configuration from the XM Card

Both confirmed and unconfirmed configurations can be sent to or received from the XM card. To open a copy of a configuration from the
XM card and display it in the PCI:

• Connect the SC-XMP programming tool to the PC using the USB cable.
• Insert the XM card into the programming tool.
• Go to File > Open From XM Card in the upper-left corner of the screen.

A message will appear when the operation is complete.

Send a Configuration to the XM Card

Both confirmed and unconfirmed configurations can be sent to or received from the XM card. To send a copy of a configuration from the
PCI to the XM card (via the programming tool):

• Connect the SC-XMP programming tool to the PC using the USB cable.
• Insert the XM card into the programming tool.

Select the Open Folder button

in the tool bar and open the intended configuration file.

• Go to File > Send To XM Card in the upper-left corner of the screen.

A message will appear when the operation is complete.

Lock the XM Card

It is important to note that this operation cannot be undone. Once the card is locked, another configuration can never be stored on it. This
operation is useful when the XM card and its configuration will be transported to another Controller, or for storing and archiving a configu-
ration. To lock the XM card so that the stored configuration cannot be changed:

• Insert the XM card into the SC-XMP programming tool.
• Verify that the correct file is stored on the XM card.
• Go to File > Lock XM Card in the upper left of the tool bar.

A message will appear when the operation is complete.

SC22-3/-3E Safety Controller Instruction Manual

60

www.bannerengineering.com - tel: 763-544-3164

P/N 133487 rev. C
