Banner SC22-3E Safety Controller with Ethernet User Manual
Page 123

Power
2-Hand Inputs
Mute Enable
Mute Sensor 1
Mute Sensor 2
Backdoor Timer
Safety Output
Max.
Time
Max.
Time
Max.
Time
Max.
Time
<
3s
<
3s
<
3s
<
3s
Mute cycle prevented
due to open Mute
Enable input
Output remains OFF
until THC is cycled
Output remains OFF
when mute cycle
expires, even though
THC is ON
Figure 69. Timing logic: two mute sensors, mute enable, two-hand control and limited mute time
SC22-3/-3E Safety Controller Instruction Manual
P/N 133487 rev. C
www.bannerengineering.com - tel: 763-544-3164
123
