Safe Limited Speed (SLS) Modes
Chapter 7
Speed Hysteresis
The [Safe Limited Speed Hysteresis] parameter provides hysteresis for the
SLS_Out output when the drive is configured for SLS Status Only and Safe
Limited Speed monitoring is active. The SLS_Out output is turned ON if the
speed is less than the Low Threshold [(Speed Hysteresis/100) x Safe Speed
Limit]. The SLS_Out output is turned OFF when the speed is greater than or
equal to the configured [Safe Speed Limit].
The SLS_Out output remains OFF if Safe Limited Speed monitoring begins
when the detected speed is less than the configured Safe Speed Limit but greater
than or equal to the Low Threshold [(Speed Hysteresis/100) x Safe Speed
Limit].
The SLS_Out output is held in its last state when the speed is less than the
configured Safe Speed Limit and the speed is greater than or equal to the Low
Threshold [(Speed Hysteresis/100) x Safe Speed Limit].
SLS Status Only Parameter
List
To configure the drive for Safe Limited Speed Status Only monitoring, set these
parameters in addition to the Safe Stop parameters listed on
Table 26 - SLS Status Only Parameters
Tab
Parameter Name
Description
Values
(Safety Configuration Tool)
Safety
Change System
Configuration
Operation Mode
Defines the primary operating mode of the speed
monitoring safety functions.
Setting:
SafeStop-Safe Limited Speed Status Only
Input
Change Input
Configuration Type
Safe Limited Speed
Configuration for the Safe Limited Speed input
(SLS_In).
Default:
Not Used
(1)
Options:
Not Used
Dual Channel Equivalent
Dual Channel Equivalent 3 s
Dual Channel Complementary
Dual Channel Complementary 3 s
Solid State Device Equivalent 3 s
Single Channel
Safe Limited Speed
Change Safe Limited
Speed Configuration
Safe Limited Speed
Monitor Delay
Defines the Safe Limited Speed Monitoring Delay
between the SLS_In ON to OFF transition and the
initiation of the Safe Limited Speed (SLS) monitoring.
Default:
0
Range:
0…6553.5 s
Safe Speed Limit
Defines the speed limit that is monitored in Safe Limited
Speed (SLS) mode.
Default:
0
Range:
0…65,535 rpm or mm/s
ratio based on revolutions or millimeters configuration
defined by the [Primary Feedback Units] parameter
Safe Limited Speed
Hysteresis
Provides hysteresis for SLS_Out output when Safe
Limited Speed monitoring is active.
Default:
0
Range:
10…100% when [Operation Mode] =
SafeStop-SafeLimitedSpeedStatusOnly
(1) You must configure this parameter with a non-zero value in this mode.
