Chapter 7
Configure Your Controller for DeviceNet Communication
b. Type a comment for each bit in the tag.
The tag name comments typed here are displayed in the Logic Editor.
c. Click OK.
11.
Click OK again to return to the Safety Slave I/O tab.
12.
Create additional safety slave input or output assemblies as required for
your application by repeating steps 3…11.
13.
To save your configuration, from the File menu, choose Save.
Use the Safety Generic Profile in RSLogix 5000 Software
You can connect to the SmartGuard slave controller by using the safety generic
profile in RSLogix™ 5000 software.
Follow these steps to connect to the controller.
1.
In RSLogix 5000 software, right-click the DeviceNet network and choose
New Module.
2.
Select Generic DeviceNet Safety Module and click OK.
3.
On the New Module dialog box, click Change.
