Chapter
11
Download and Verify
Introduction
Download the DeviceNet
Network Configuration Before you download, you must go online to the DeviceNet network by using
RSNetWorx for DeviceNet software. Your computer and the devices you wish to
communicate with must be connected to the DeviceNet network. Or, if you are
running your controller in standalone mode, your computer must be connected
to the SmartGuard controller’s USB port.
If you are connected to the SmartGuard controller using EtherNet/IP protocol,
you need to follow the steps in this section. When connected to the SmartGuard
via the EtherNet/IP protocol, you are essentially bridging through the
SmartGuard controller to the DeviceNet network, and then going online,
downloading and monitoring. Though this chapter deals with using DeviceNet
protocol, you need to follow the same steps for EtherNet/IP protocol.
When you go online to a DeviceNet network, RSNetWorx for DeviceNet
software browses the network one time and shows you the devices on the
network. It does not read (upload) or change (download) the parameters of any
of the devices.
The graphics representation of the network created by the browse operation
remains static. It does not automatically update to show changes since the last
browse, unless the Continuous Browse option is selected.
Topic Page
Download the DeviceNet Network Configuration 159
Verifying Your DeviceNet Safety Configuration 161
Start the Safety Device Verification Wizard 161
Determine if Devices Can Be Verified 161
Select Devices to Verify 163
Review the Safety Device Verification Reports 164
Lock Safety Devices 166
View the Safety Device Verification Wizard Summary 167
