Rockwell Automation 1752-L24BBBE SmartGuard 600 Controllers User Manual User Manual
Page 192
192
Rockwell Automation Publication 1752-UM001E-EN-P - June 2014
Appendix A
Controller Specifications
Radiated RF immunity
IEC 61000-4-3:
· 10 V/m with 1 kHz sine-
wave 80% AM from
80…1000 MHz
· 10 V/m with 1 kHz sine-
wave 80% AM from
1.4…2.0 GHz
· 10 V/m with 200 Hz 50%
Pulse 100% AM at 900
MHz
· 10 V/m with 200 Hz 50%
Pulse 100% AM at 1200
MHz
· 3 V/m with 1 kHz sine-
wave 80% AM from
2000…2700 MHz
IEC 61000-4-3:
· 10 V/m with 1 kHz sine-
wave 80% AM from
80…1000 MHz
· 10 V/m with 1 kHz sine-
wave 80% AM from
1.4…2.0 GHz
· 20 V/m with 200 Hz 50%
Pulse 100% AM at 800,
900, 1200 MHz
· 3 V/m with 1 kHz sine-
wave 80% AM from
2000…2700 MHz
EFT/B immunity
IEC 61000-4-4:
· ±2 kV @ 5 kHz on power
ports
· ±2 kV @ 5 kHz on signal
ports
· ±2 kV @ 5 kHz on
communication ports
IEC 61000-4-4:
· ±2 kV @ 5 kHz on power
ports
· ±1 kV @ 5 kHz on signal
ports
· ±1 kV @ 5 kHz on
communication ports
Surge transient immunity
IEC 61000-4-5:
· ±1 kV line-line (DM) and
±2 kV line-earth (CM) on
power ports
· ±1 kV line-line (DM) and
±2 kV line-earth (CM) on
signal ports
· ±1 kV line-earth (CM) on
communication ports
IEC 61000-4-5:
· ±500V line-line (DM) and
±1 kV line-earth (CM) on
power ports
· ±1 kV line-earth (CM) on
signal ports
· ±1 kV line-earth (CM) on
communication ports
Conducted RF immunity
IEC 61000-4-6:
· 10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz
Attribute
1752-L24BBB
1752-L24BBBE
