Rockwell Automation Publication 1752-UM001E-EN-P - June 2014 189
Appendix
A
Controller Specifications
Introduction
General Specifications
Topic Page
General Specifications 189
Environmental Specifications 191
Certifications 193
Attribute 1752-L24BBB 1752-L24BBBE
Dimensions (HxWxD), approx. 99.0
(4)
x 99.4 x 131.4 mm
(5)
(3.90
(4)
x 3.91 x 5.18
(5)
in.)
99.0
(4)
x 113.0 x 131.4
(5)
mm
(3.90
(4)
x 4.48 x 5.18
(5)
in.)
Weight, approx. 460 g (1.23 lb) 575 g (1.54 lb)
DeviceNet current load, max 15 mA @ 24V DC
Supply voltage
(1)
20.4…26.4V DC (24V DC, -15…10%)
Inrush current - unit power supply 4.8 A peak for 600
µs @ V0/G0
Inrush current - safety input power
supply 2.6 A peak for 3 ms @ V1/G1
DeviceNet voltage range 11…25V DC
Current consumption
(V0 - internal logic circuit) 230 mA @ 24V DC 280 mA @ 24V DC
Overload protection Shut down of the affected output with cyclic reconnecting
Isolation voltage 50V, Functional insulation type
Tested at 600V AC for 60 s, between all groups
Wire type Copper
Wiring category
(2)
2 - on power, signal, and
communication ports 2 - on power, 1 - on signal, 1 -
communication port
Wire size For power supply and I/O, use 0.2…2.5 mm
2
(12…24 AWG) solid wire, or
0.34…1.5 mm
2
(16…22 AWG) standard flexible wire. Before connecting,
prepare standard wires by attaching ferrules with plastic insulation collars
(DIN 46228-4 standard compatible)
For Ethernet connections:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e
Minimum cable according to TIA 569-B.1 or Category 5 cable according to
ISO/IEC 24701
I/O terminal screw torque 0.56…0.79 N•m (5…7 lb•in)
North American temperature code T4A
Input type Current sinking
Voltage, on-state input, min 11V DC
