Application and Configuration Examples Appendix F
Light Curtain Application This example shows a dual channel safety light curtain with manual reset and
dual channel emergency stop switch with manual reset.
Figure 107 - Wiring Diagram
1
0
3 5
2 4 6
7 9
8
1 3
0 2 4
5
V1 G1 T0
T1
T2
T3 O1
O0
V2 G2 O3 O5
O2 O4 O6
O7
M
KM1
KM2
E1
E2
KM1-NC
KM2-NC
KM1 KM2
S2
S1
S3
Connect a 24V dc power supply to terminals V0 and G0, the power supply terminals for internal circuits.
E1 and E2: 24V dc Power Supplies
S1: Reset Switch
S2: Reset Switch
S3: Emergency Stop Push Button
KM1 and KM2: Contactors
