Relay action – the option is not accessible until the virtual port is selected in
the Used relay block. Only then you can select the required relay action.
Switch on – this option helps close the relay of the below–specified port
whenever some of the conditions defined in the
block Event parameters
is met.
Switch off – helps open the relay of the below–specified port whenever
some of the conditions defined in the
block is met. Event parameters
Positive pulse – helps activate the relay of the below specified virtual port
for a period defined in the Relay pulse width parameter after one of the
conditions specified in the Event parameters is met.
Negative pulse – helps deactivate the relay of the below specified virtual
port for a period defined in the Relay pulse width parameter after one of
the conditions specified in the Event parameters is met.
Relay pulse width – if Positive pulse or Negative pulse is set above, define
the pulse width in milliseconds.
Report on inactive notification
The block sets how an inactive event shall be reported.
Message – specification of the text of the SMS to be sent whenever the selected
event ceases to exist, becomes inactive. If the Message field is left blank, no
SMS will be sent. In addition to standard texts, selected dynamic strings may be
entered (see above).
Relay action – the option is not accessible until the virtual port is selected in
the Used relay block. Only then you can select the required relay action.
Relay pulse width – if Positive pulse or Negative pulse is set above, define
the pulse width in milliseconds.
Parameter evaluation
Active notify evaluation – specify the SMS sending conditions. The following
options are available:
Independent by parametr – reports on active/inactive events are sent
for each parameter separately, independently of the states of the other
parameters.
At least one parameter active – reports are sent for each parameter
with an active event separately, independently of the states of the other
parameters. If the %k string is used in the SMS text, the SMS always
includes a list of parameters with an active event. The inactive event report
is not sent until the event ceases to exist for all the parameters.
All parameters active – this selection represents a logical AND of all
selected parameters. The report is sent only if the event condition is met
for all the selected parameters. The inactive event reports are sent for each
parameter separately, independently of the states of the other parameters.
If the %k string is used in the SMS text, the SMS always includes a list of
parameters with an inactive event.
Deglitch active change shorter than [s] – this parameter limits evaluation of
active events in the case of rapid changes. If a selected event takes a shorter
time than as defined, it will not be evaluated as active.
Deglitch inactive change shorter than [s] – this parameter limits evaluation
of inactive events in the case of rapid changes. If a selected event ceases to exist
in a shorter time than as defined, it will not be evaluated as inactive.
