By Call Type

This router is based on routing according to the call type (voice, data, video, etc.). All
the columns have the same meanings as the case is with the By called number subtype
except for the first one. The first column defines the call type. When a preset call type
is recognised, the call is routed to the preset destination.

By Port

This router is based on routing according to the incoming port (the call comes into the
PBX through this port). All the columns have the same meanings as the case is with
the By called number subtype except for the first one. The first column defines the
port. When a preset port is recognised as the incoming port, the call is routed to the
preset destination.

Message routing

The last router type is an SMS router, which routes SMS messages according to their
texts. This router can also be created in the

menu and cannot be

Routing – Routers

used for call routing. It consists of five columns with the following meanings:

Prefix – use this column to enter a text string to be recognised at the SMS
beginning. After recognition, the SMS message is routed through the PBX
according to the preset rule.
Replace– use this column to edit SMS messages. You can either replace the
existing text with another one or insert instructions with the following meanings:

%c – inserts the sender number (CLI).
%l – inserts the receiver number (CPN).
%se – erases the whole text of any length. If you leave the Replace
column empty, it is translated as 'Don't change the incoming text'.
%sr(B,E) – inserts the original string omitting the first

number of

characters and the last E number of characters.
%ss("STRING",X,N) – finds the

appearance of the

in the

X–th

STRING

incoming SMS message. From this point on, you can leave letters of the

incoming text deleting all the others. By setting to zero, you insert the

whole text (from the mentioned point to the message end).
%sm(B,L) – from the

character of the SMS message on, you can

B–th

insert characters of the original text. By setting to zero, you insert the

rest of the text.

Destination type– this column sets the type of destination to which an incoming
SMS message is routed by this rule. Choose one of the destinations used for SMS
routing only. In this column you can find two options that need more
explanation:

Default – use this option to route the incoming SMS to the next routing
level (if any). It is generally used for sorting objects into sets. With the

option, the incoming SMS is routed back to the superior set and

Default
the next set item is used.
Disabled – use this option to terminate the incoming SMS routing
immediately. The SMS message will not be delivered!

Destination Id – this column sets a destination of the above–selected
destination type.
Time condition – use this column to set a time condition for each router row.
