133
6.13 Status Control parameters
The Global data – Status Control parameters menu is used for defining states of
the Status Control objects created in the Routing – Routing objects – Status
Control objects menu. Figure 1 shows an overview of the parameters to be defined.
You can add and remove the rows using the right-hand mouse button context menu
Figure: Pohled na menu Status Control parametry
The meanings of the columns are as follows:
State – define the state of the Status Control object. The following options are
available:
, , and . Ready Unready OK Error
State name – this optional parameter makes identification of multiple states
easier.
Message text – based on a match of the text entered here and the text of the
message sent to the Status Control object, the proper state is selected for the
Status Control object.
Called number – based on a match of the number entered here and the CPN,
the proper state is selected for the Status Control object.
Tone after set – this tone is played to the calling subscriber whenever a Status
Control object state change occurs. If the tone is not set, the call will not be
answered in the Status Control object (i.e. the call will not pass into CONNECT),
but the state change will be executed.
State color – assign one of the available colours to the object. Whenever the
Status Control object state changes, its colour will change accordingly in the
Operator menu of the 2N® NetStar Assistant. Should one state be assigned
multiple colours in the table, the colour of the first state is used for all identical
states.
A user must have the Operator administration right in order to
display the Operator menu in the Assistant. Refer to 2N NetStar
®
the Users – User rights menu for the user right settings.
Click on the column header to arrange the rows in the ascending or descending order
according to their names or numerical values in the cell.
