7.6 Identification Tables
What Is Identification Table?
The identification tables are used for changing the calling extension numbers. To create
and modify them use the
menu. To view an Routing – Identification tables
identification table, assign it to a virtual port or a virtual port type. The setup menu
consists of two windows. A list of available identification tables is on the left. To
configure a selected identification table, use the right–hand window. The context menu
on the left side of the menu consists of the following options:
Add – use this option to add an identification table.
Delete – use this option to delete a selected identification table. If you delete an
identification table, all the associate settings are removed from the database
(e.g. assignment to a carrier).
Rename – use this option to rename an existing identification table.
Default – use this option to delete all current identification tables and create
default identification tables. These tables have already been filled with
corresponding objects (extensions, users, etc.).
Update – use this option to update a selected identification table according to
the selected type. Select the type via a dialogue box. Earlier identification table
records are not deleted.
Update all – use this option to add default identification tables and preserve all
already existing ones.
Figure: View of Identification Table Configuration Menu
Example
Suppose extension 1234 assigned to user Rubas Marek is calling through the virtual
port with the assigned identification table from Figure 1. To change the extension
identification proceed as follows:
First create number 261 301 000 of the National subtype.
Then, change the last three digits according to the original extension number –
234 as shown in row 1 to get number 261 301 234.
Finally, set the ISDN numbering plan, Screening and Presentation, which are
transmitted via DSS1 signalling. Also, disable the Facility and Redirecting
parameters independently of the previous routing.
