By Called Number Subtype
This router is based on routing according to the called number subtype (CPN subtype).
The called party number subtype is the only parameter that comes into the router and
cannot be changed there. The router consists of five columns with the following
meanings:
Subtype– is a part of the identification to be used for call routing. You can set
five subtypes:
Internal – represents an internal phone number specified by the PBX
administrator.
Local – represents a private network phone number in the local format.
National – represents a public network number in the national format with
prefixes.
International – represents a public network phone number in the
international format with prefixes.
Unknown – an unknown number format relating to none of the above
mentioned subtypes.
Destination type– this column sets the type of destination to which an incoming
is routed by this rule. Choose an item from the list of all available PBX routing
objects. In this column you can find three options that need more explanation:
Default – use this option to route the incoming call to the next routing
level (if any). It is generally used for sorting objects into sets. With the
Default option, the incoming call is routed back to the superior set and the
next set item is used.
Disabled – use this option to terminate the incoming call routing
immediately. The calling user will hear the congestion tone.
Origin – use this option to return a modified number from the given router
back to the incoming port (through which it came to the PBX).
Destination – here select a destination of the above–selected destination type.
Tone – in this column define the tone to be played to the calling user after prefix
dialling in case that a router is the next destination.
Time condition – use this column to set a time condition for each router row.
The routing rule is valid only during the time condition validity period. Time
conditions help you create sophisticated routing schemes according to time. You
can route a call to different destinations for the same incoming conditions (except
for time).
Default destination – if no match is found in the
column, the call is Prefix
routed as defined in this option (located below the routing rule table):
Type – in this part set the type of destination to which an incoming call is
to be routed. Choose an item from the list of all available PBX routing
objects.
Id – in this part select the destination of the above–selected destination
type.
By Calling Number Subtype
This router is based on routing according to the calling number subtype (CLI subtype).
The router consists of five columns with the same meanings as the case is with the By
called number subtype. The only difference lies in that the CLI subtype is the only
parameter coming into the router and cannot be changed there. The calling party
number subtype changes made in this router are only used for routing and not for call
identification.
