72
calling number and name matching.
Insert calling station name – define whether the calling station name shall be
added to the outgoing INVITE message.
Own channel count – shows the count of voice channels that can be served by
the virtual port.
Licences needed
In this section, you can check easily whether the or Mobility Extension Call
licence is required on the virtual port. If a licence is required yet absent or Recording
insufficient, it is in red letters here. If a licence is valid, the blue text
is Valid licence
displayed.
Properties
The Properties tag consists of a number of subtags, which are described in a separate
chapter. This tag is exceptional because almost all of its parameters obey the
hierarchical rules. For the hierarchy and parameter details refer to Chapter
Setting
. Properties
Progress info
The parameters in this tag help you enable/disable progress tones that are to be
played back to the user. In some cases, the progress tones are generated by the PBX,
in others they are transmitted from the network. The final effect depends not only on
the user's virtual port, but also on a combination of the user's virtual port (mostly an
internal PBX port) setup and the other party's virtual port (a public network port or
another internal PBX port).
The port generates the network progress info to the opposite port:
Dial tone – the port is a source of the network dial tone for the opposite
port if the latter requires the dial tone.
Alert tone – the port is a source of the network alert tone for the opposite
port if the latter requires the alert tone.
Disconnect tone – the port is a source of the network
disconnect/congestion/busy tone for the opposite port if the latter requires
the disconnect tone.
Setting options
Default – provides fall–down to the next level (virtual port type).
Yes – enables use.
No – disables use.
Conditionally – if a tone is signalled by the network, the generated tone is
played. If a tone is not signalled, the internal PBX tone is played. The
section is applied to this setting only. This setting is Reset condition
recommended especially for the SIP Gateway virtual port.
The port requests progress info from the PBX or the opposite port:
Dial tone – the port requests the dial tone from the PBX or the opposite
port that generates the dial tone.
Alert tone – the port requests the alert tone from the PBX or the opposite
port that generates the alert tone.
Disconnect tone – the port requests the disconnect tone from the PBX or
