Identification tab 7.3
94
Configuration of Identification tab
If you select some identification tab on the left side of the menu, you can setup it on the right side.
Window for configuration can be logically divided into four parts – Calling party determination,
New identification determination, Advanced settings and Default destination.
Calling party determination
Calling party determination is performed at the beginning of each identification table row. Here
define the object to which the below-selected identification rule will be assigned. For this purpose,
use the following parameters:
Type – In this column you have to set up type of calling party, for which is this row set. You can
choose between options every, station, station type, user, group, virtual port and virtual port
type.
Id – With this column you have to define specific calling party within selected type (e.g. specific
station).
Scheme – Within this column you can specify if calling party identification is presented as number,
URI or if it isn't specified (option Every).
Subtype – This column defines calling party number subtype before identification changing. You can
choose between options Unknown, Internal, Local, National, International and Every. Option
Every you can use if you aren't sure which number subtype is used. The parameter Subtype you can
use only if parameter Scheme is set to option Number.
CPN prefix – With this column you can obtain that same station is identified differently according to
called number.
New identification determination
New identification determination is provided in the second part of each row. Background of this
part can be yellow highlighted. The identification rule sets completely new calling party identification
via five columns with following meaning:
Scheme – Within this column you can define if calling party is after using of this row identified by
new number, URI or if previous identification is used. Subtype – If column Scheme is set to option
Number, you can choose new calling party number subtype between options Unknown, Internal,
Local, National and International. Number – Set number will be used for creating of the new
calling party identification within this row. Replace from end – This parameter sets number of new
CLI digits (set within column Number), which will be replaced by old CLI digits. If old calling party
number isn't known, created CLI is same as number set within parameter Number. Add to begin –
With this parameter you can add another digits to the beginning of the new calling party number.
Advanced settings
For each row of the identification tab you can setup advanced parameters – numbering plan,
screening and presentation, which are transmitted via DSS1 signalling. In addition you can disable
Facility and Redirecting, which are used within some networks.
Numbering Plan – This column sets up used numbering plan for each row of the tab.
Screening – This column sets up screening information for each row of the tab.
Presentation – This column sets up presentation restrictions for calling party number for each row
of the tab.
Disable Facility – With this option you can disable Facility for selected row of the identification tab.
Disable Redirecting – With this option you can disable Redirecting for selected row of the
identification tab.
