Routing objects 7.2
74
rule within row with time condition is valid only in the time when is valid preset time condition.
Thanks time conditions you are able to create sophisticated routing according to the time. For the
same incoming conditions (except time) you can route the call to different destinations.
Default destination – If incoming SMS message text doesn't correspond to any of the preset
strings, the SMS message is routed to this default destination (set within the section below the
window with rules):
Default type – This part sets type of destination, where you want to route incoming SMS message.
You can choose only from destinations that can be used for SMS routing.
Default Id – This part sets specific destination of previously selected destination type.
7.2 Routing objects
7.2.1 Bundles
Bundle
The bundle is routing object, which enables to route incoming call to one of the specified objects.
Choosing of the object within the bundle depends on the selected strategy. If is specified routing
object busy it needn't to conduce to routing termination. That call can be routed to another routing
object. It depends only on setting if call is routed again immediately or after specified timeout. All
parameters and their usage are described below.
Bundle setting
Bundles you can set up in the menu Routing – Routing objects – Bundles . On the left side of the
menu is displayed list of created bundles. Via context menu you can add, delete or rename bundles.
You can also create predefined bundles via option Default. If you select one of the bundles, on the
right side of the menu you can set up all its parameters. Following figure shows possible configuration
of the bundle with three carriers.
