SIP virtual ports 3.6
33
Module IMEI – This field shows detected IMEI number.
GSM network diagnostic
State – This field shows actual state of the port. According to this state you are able to detect some
problems with logging into the network. For example the state PIN REQUESTED means, that SIM card
needs PIN code, which you have to insert or you can also disable PIN requesting at the SIM card.
Otherwise the SIM card can't be logged into the network.
Logged network – This field shows actual network code. It is international code of the network into
which is SIM card logged at the moment.
Network name – This field shows name of the network into which is SIM card logged at the
moment.
Signal – This parameter shows actual level of the signal (if it is activated). When the level of the
signal is low, it could be reason for logout from the network. Sometimes it can happen that SIM card
is logged, but you are not able to realize calls because of higher error rate.
SIM number – This field shows detected number of inserted SIM card.
PIN – To this field you have to enter the PIN code if it is required and it wasn't entered within the
menu SIM – SIM cards for this SIM card.
PUK – To this field you have to enter the PUK code if it is required and it wasn't entered within the
menu SIM – SIM cards for this SIM card.
SMS centre number – To this field you have to enter the SMS centre number if it is required and it
wasn't entered within the menu SIM – SIM cards for this SIM card.
3.6 SIP virtual ports
3.6.1 SIP Gateway
SIP gateway virtual port is used for creating trunk between two PbXs or to connect your PbX to the
public network via one of the VoIP providers. All parameters are divided into logical sections.
Stack status
This field displays information about stack and its actual state.
Basic parameters
Port – Here you have to fill in number of used UDP or TCP port (it depends on following setting) for
communication with opponent.
Transport layer – It defines transport layer of this interface. You can choose between TCP and
TCP&UDP. If you use both, higher priority has UDP, but for packets longer then 1300 bytes will be
used TCP protocol.
Realm – It defines own address used within header From.
Via header – It defines content of Via header. You can choose between following options:
IP address – Via header is filled with CPU IP address.
FQDM – Via header is filled with PbX hostname, which was entered on the IP interface of the PbX.
NAT – In this case is filled static IP address of NAT. NAT has to be configured corretly, else
signalization from opponent can't reach your PbX.
STUN – Here you can enter address and port of STUN server, used for discovering actual address
behind NAT.
Authorization required – With this option you can enable authorization for your opponent. For
authorization are used data from user logins.
