Routers 7.1
72
columns with the same meaning as in the case of router by called number. Difference is only that in
this case presents prefix calling party number and you can't use instructions for delayed dialling.
Calling party number changes made within this router are used only for routing and not for call
identification.
c) By called number subtype
This router is based on routing according to the called number subtype (CDN subtype). Called party
number subtype is only one parameter which comes to the router and you can't change it there.
Router consists of five columns with following meaning:
Subtype – Number subtype is part of identification which can be used for call routing. You can set
five different subtypes:
Internal – It represents internal phone number specified by PbX administrator.
Local – It represents phone number within the private network in local form.
National – It represents phone number within the public network in national form with prefixes.
International – It represents phone number within the public network in international form with
prefixes.
Unknown – Unknown number format. It doesn't correspond to any of previous mentioned subtypes.
Destination type – This column sets type of destination, where you want to route incoming call via
this rule. You can choose between all routing objects (if they are created). In this column you can
find three options which need more detailed description:
Default – If you use this option, incoming call is routed directly to another routing level (if any
exists). It is used generally in the case of sets using. With option Default is incoming call routed
back to the superior set and routing continues to another row within this set.
Disabled – If you use this option, routing of incoming call is immediately terminated. Calling user
hears congestion tone.
Origin – This option returns changed number from the specific router back to the incoming port
(through this port came call to the PbX).
Destination Id – This column sets specific destination of previously selected destination type.
Tone – In this column you can define tone, which is played to the calling user after prefix dialling in
the case that another destination is router.
Time condition – With this column you can set time condition to each row of the router. The routing
rule within row with time condition is valid only in the time when is valid preset time condition.
Thanks time conditions you are able to create sophisticated routing according to the time. For the
same incoming conditions (except time) you can route the call to different destinations.
Default destination – If incoming call doesn't correspond to any of the preset called number
subtypes, the call is routed to this default destination (set within the section below the window with
rules):
Default type – This part sets type of destination, where you want to route incoming call. You can
choose between all routing objects (if they are created).
Default Id – This part sets specific destination of previously selected destination type.
d) By calling number subtype
This router is based on routing according to the calling number subtype (CLI subtype). Router
consists of five columns with the same meaning as in the case of router by called number subtype.
Difference is only that in this case represents preset subtype, subtype of the calling party number
