Routing objects 7.2
90
you see here Unknown, then is assigned binary port probably configured as Output or is this port or
whole board out of order.
Tone connected – It sets announcement played to the calling user when detector is in state active.
Tone disconnected – It sets announcement played to the calling user when detector is in state
deactive.
Tone events enabled – It sets announcement played to the calling user in the case of checked
option Send events.
Timeout – With this parameter you can set duration of the call. After timeout expiration is call hung
up (if following option isn't checked).
Play whole tone – With this option you can enable playing whole tone independently of preset
timeout.
Send events – With this option you can enable SMS sending for predefined events.
Send as user – With this parameter you have to define user who will be used as SMS sender. This
user need to have correctly defined routing for SMS messages.
Destination for events – This section defines destination for sending events messages.
Figure 2 View of configuration menu of routing object Binary I/O used as detector.
Messages for events
Sending events – It displays actual state of events sending. If sending is enabled, messages can be
