1.5 PbX activation
What do you need?
To activate and set up 2N Netstar you need the 2N Netstar itself, x86 computer running supported
operating system Windows, keyboard and mouse. PbX have to be connected in the network with 2N
Netstar. It is also necessary to display the redirected standard input and output of 2N Netstar on your
PC's console. For this you need a six-core cable with a six-pin connector RJ-12 on one end and a
serial connector on the other end. This cable is supplied as standard equipment. As a console, you
may use, for example application "Tera Term Pro" or any other functional console. It is possible to
work in "Hyperterminal", but longer listings are interlaid.
Step 1: IP address setting
Prior to starting the configuration you need to set up the IP address of the communication system
and provide network communication between the system and the computer, from which the system
will be configured. The IP address can be set up using a serial console or by connecting to a default IP
address 192.168.100.100. Communication with 2N Netstar can be on-line or off-line. Console has to
be set according to following table:
Speed 115200
Bits 8
Parity None
Stop bits 1
Flow control None
Step 2: Hardware activation
After first connection to the selected PbX according to the chapter Connecting to the PbX is
displayed configuration wizard from figure 1. This wizard is displayed only if PbX has new empty
database (wasn't preconfigured according to your demands).
