Board list 2.4
21
2.4 Board list
This overview you can find in the menu Hardware – Board list . Within this menu is displayed list of
boards, which are physically present in the PbX. Boards list is displayed in four columns with following
meaning:
Address – It shows physical board address within the PbX according to the chapter Addressing.
Type – It shows board type.
Serial number – It shows board serial number, which was burned at production.
MAC address – It shows board MAC address.
2.5 Port list
This overview you can find in the menu Hardware – Port list . Within this menu are displayed all
physic ports sorted by address. List of physic ports consists of six columns with following meaning:
HW Address – It shows physical board address within the PbX according to the chapter Addressing.
Board – It shows type of the board for each physic port.
Virtual port – It shows complete name of the carrier, which is aasigned to specific physic port.
Stack – It shows type of assigned carrier (DSS1, ASL, CO, ...).
Station – It shows list of stations, which are assigned to the carrier of specific physic port.
User – It shows users of assigned stations for each physic port.
State – It shows actual state for each port.
Description – Supplementary information.
