How the Buttons Work

On the front of the lightbar, there are six buttons. The buttons on the left and right sides of the lightbar work in
different ways.

Action buttons (on the right of the screen)

On the main guidance screen:

Press

or

to scroll through the action icons.

Press

to select the highlighted icon.

The following icons may appear to the right of the guidance screen:

ICON

DESCRIPTION

ICON

DESCRIPTION

Reset guidance

Nudge left

Set Point A

Nudge right

Set Point B

Pause guidance

Start headland

Resume guidance

Complete headland

Change zoom scale

Pause swath recording

Go to main
Configuration menu

Resume swath recording

Change view mode

Currently recording FreeForm curve (press to stop)

Next FreeForm
segment

Not currently recording FreeForm curve (press to start)

Shift AB Line

Display point, line and area mapping icons

Display panning
icons

Note: Action icons appear only when they are appropriate. They are not all visible at all times.

The following action icons may appear on the right of a configuration screen:

ICON

DESCRIPTION

ICON

DESCRIPTION

Increase value / up to next option

Proceed to next screen

Decrease value / down to next option

Accept settings
