Confirm the OmniSTAR settings. 7.
The OmniSTAR XP/HP or VBS corrections are now configured.
Configuring RTK
Note: If you want to use RTK corrections and output NMEA messages at the same time, you must connect the
radio to the COM port on the lightbar and the NMEA device to the AUX port. Set the NMEA port to AUX in the
NMEA output Port Parameters screen.
Note: You should turn off coverage logging before changing RTK configuration settings. Otherwise, you may get
a jump in the coverage logging due to a momentary loss of GPS corrections while changing settings.
To configure RTK corrections, select the appropriate protocol:
ITEM DESCRIPTION
CMR For TSIP, European Pac Crest, or SiteNet 450 radios
TrimbleRadio For the SiteNet 900 radio
The remaining RTK options change depending on which protocol is selected.
CMR protocol
Set the Baud Rate, Data Parity, and Stop Bits for the rover radio. 1.
