ITEM DESCRIPTION
1 External interface cable (P/N 62749)
2 To RTK radio
3 RTK radio cable
4 EZ−Guide 500 power cable (P/N 62817)
5 Port expansion cable (P/N 62609)
6 Connect COM 2 port connection cable (P/N 63076) and then NMEA device
External Receiver Support
The EZ−Guide 500 lightbar can recieve GPS positions from TSIP−compatible recievers. This enables you to use
any of the correction types available on your receiver, including OmniSTAR, Beacon, and RTK.
The following TSIP−compatible recievers are supported by the EZ−Guide 500 lighbar:
Trimble Case IH Ag Leader New Holland
AgGPS 252 AFS 252 GPS 5100 NH 252
AgGPS 332 − − −
68
