Step 6: Driving and defining the guidance line
Depending on the pattern type that you selected, one of the following icons is now available:
(start AB Line, A+, Identical Curve, Adaptive Curve, or Pivot)
•
(start Headland)
•
(not currently recording FreeForm curve)
•
Drive to the start point and then select one of these icons to begin defining guidance.
For more information about the various field patterns, see Guidance Patterns.
Adding an AB Line
To create a new AB Line, the New AB Line wizards takes you through the following steps:
Select the pattern type. 1.
Set up the implement. 2.
Set up any additional pattern requirements (if necessary). 3.
Drive and define the guidance line. 4.
Step 1: Selecting the pattern type
Note: If the pattern type and implement setup are already correct, just press .
Press to select Pattern Type. 1.
42
