The two status text items at the top of the screen show your current position relative to the pause position:
ITEM DESCRIPTION
Distance The vehicle's current distance from the pause position.
Heading
The vehicle's current direction relative to the pause position.
For example:
0° = pointing directly toward the pause position
180° = pointing directly away from the pause position
To pause guidance, select the icon and then press .
When you pause guidance:
The current guidance line that you were on is displayed, even if you drive onto another swath.
•
The pause function remembers your position even if the lightbar is turned off.
•
A straight, dotted line is drawn from the pause position to the position of the vehicle.
•
Returning to the pause position
Turn the vehicle until the Heading status text item is 0.0° (so you are heading directly toward the pause
position). 1.
Drive forward until the Distance status text item is close to 0.00 m (0' 0"). This means you are nearly
back at the pause position. The paused vehicle outline should be visible on the lightbar screen. 2.
Position the vehicle directly over the paused vehicle outline. 3.
Select the icon and then press to resume guidance. 4.
37
