In setup screens, the icons match the buttons beside them.
Function buttons (on the left)
Beside each function button, there is an icon. When you press the function button, you select the feature that is
shown on the icon.
ITEM DESCRIPTION
1 Coverage logging icon
2 Middle function button
The following function icons may appear beside the buttons on the left of the screen:
ICON DESCRIPTION ICON DESCRIPTION
Display information tab window Cancel changes
Turn on coverage logging Go up one menu level
Turn off coverage logging Return to guidance screen
Zoom in Move back one screen
Zoom out Display Help
Escape (ESC) button
Press the Escape button on the back of the lightbar to cancel out of screens and to move up menu levels. See Back
of the Lightbar.
Getting help
6
