ITEM DESCRIPTION
Zooms to the extents of the field. This includes the field boundary (if present), coverage logging
and any mapped features.
Zooms in
Zooms out
Note: To ensure all coverage logging is shown, turn off coverage logging before entering panning mode.
Otherwise, the coverage polygon currently being recorded will not be shown in panning mode.
User Modes
The EZ−Guide 500 lightbar guidance system has two user modes:
MODE DESCRIPTION
Easy
Limited to accessing the most simple features
Fewer action icons are available
Simplified driver options (for example, creating a guidance line is easier)
Advanced The user can access all of the settings.
Use Easy mode if you want to select a swath pattern and quickly begin driving.
Changing the User Mode
To change between Easy mode and Advanced mode:
Select Configuration / User Mode. The User Mode screen appears: 1.
Select Advanced or Easy and then press . The main guidance screen reappears, with the lightbar in
the selected mode.
2.
17
