Drive to the start point of the master line. 1.
Set the A point: 2.
Press or until you have selected the icon. a.
Press . The A point is set. b.
Drive to the other end of the line. 3.
Ensure that the icon is selected and then press . The master AB Line appears. 4.
Turn left or right for the next swath. As you move toward the next swath, it appears on the screen and
turns orange to show that it is selected. 5.
A+ Line
An A+ line is also a straight line. It is defined by a single point on the line (the A point) and the heading of the
line.
PATTERN EXAMPLE
When you choose to create an A+ line, you enter the heading.
The default heading is the same as the previous AB Line. This pattern is useful for when you need guidance
exactly parallel to the last AB Line, for example when:
driving adjacent fields
•
mapping the AB Line on a road down the side of the field
•
skipping an access road in a field
•
The A+ line extends 1 km (0.6 miles) before and after the A point.
