line and save it. This can be useful for higher accuracy work, for example, to offset planting by half a swath width
from one season to the next.
To shift the lines:
Drive the vehicle along the line that you want to map the guidance to. 1.
Note: If you are driving at an angle of more than 10 degrees from the current swath, an error message
appears. You must drive at almost the same angle as the guidance line.
Select the action icon. The Shift to Here screen appears: 2.
Select one of the following: 3.
Item Description
Cancel Exit without moving the guidance line
Shift but Don't Save
The line moves to your current location, but when you exit the field the previous
line position is retained
Shift and Save New
The line moves to your current position and is permanently saved in the new
location
Configuring the Lightbar
Setting the LED brightness
You can adjust the brightness of the LEDs on the lightbar. In bright sunlight, increase the brightness to make the
LEDs more obvious. In darker conditions, for example, driving at dusk, you can lower the brightness settings to
make the LEDs less intense.
To change the LED brightness, select Configuration / System / Display / LED Brightness.
Setting the backlight brightness
The backlight brightness controls the brightness of the lightbar screen.
To adjust the setting, select Configuration / System / Display / Backlight.
55
