Setting the information tab transparency
For a description of the information tabs, see Information tabs.
The information tabs are transparent. To change the level of transparency, select Configuration / System / Display
/ Status Popup Transparency.
10 represents a solid black tab; 1 is barely visible.
Setting the LED mode
There are two LED modes:
Mode Description
Chase (default)
Chase the LEDs to stay online. The LEDs represent the swath location relative to the vehicle.
For example, if the vehicle moves offline to the left, the lit LEDs move right.
Pull
Center the LEDs to stay online. The LEDs represent the vehicle position relative to the swath.
For example, if the vehicle moves offline to the left, the lit LEDs also move left.
To change the LED mode, select Configuration / System / Guidance / LED Mode.
LED spacing
The LED spacing is the distance that each LED represents. The default LED spacing is 15 cm (6").
To adjust the LED spacing, select Configuration / System / Guidance / LED Spacing.
Setting the units
The units that you selected during the Quick Start Wizard are set as the units for the lightbar. The default units are
US/imperial.
To change the units, select Configuration / System / Display / Units.
Setting the time zone
The lightbar receives the time from the GPS signal, which transmits UTC (Coordinated Universal Time, formerly
known as Greenwich Mean Time).
To enter your time offset from UTC so that the lightbar can calculate your local time, select Configuration /
System / Display / Time Zone.
Common time zones are listed below.
Location Standard time offset Daylight savings time offset
US Eastern Time −5:00 −4:00
