Changing the Backlight Brightness
To change the strength of the screen backlight, select Configuration / Backlight.
Changing the LED Brightness
To adjust the brightness of the LEDs on the lightbar, select Configuration / LED Brightness.
In bright sunlight, increase the brightness to make the LEDs more obvious.
•
In darker conditions, for example driving at dusk, you can lower the brightness settings so the LEDs are
less intense.
•
Getting GPS Corrections
By default, the EZ−Guide 500 lightbar is configured to receive the following free corrections:
REGION CORRECTION
North America WAAS
Europe EGNOS
These corrections provide 15 cm−20 cm (6 in−8 in) pass−to−pass accuracy.
To change the GPS corrections (for example, to configure RTK or OmniSTAR VBS/HP/XP), select
Configuration / GPS Setup / GPS Correction Source.
External Receiver Support
The EZ−Guide 500 lightbar can recieve GPS positions from TSIP−compatible recievers. This enables you to use
any of the correction types available on your receiver, including OmniSTAR, Beacon, and RTK.
The following TSIP−compatible recievers are supported by the EZ−Guide 500 lighbar:
Trimble Case IH Ag Leader New Holland
AgGPS 252 AFS 252 GPS 5100 NH 252
AgGPS 332 − − −
To enable TSIP messages as the correction source:
Connect the receiver to the lightbar and then turn them on. 1.
Select Configuration / GPS Setup. 2.
Change the GPS Correction Source option to Ext. TSIP. 3.
Select Continue and press . The Connecting to External Receiver screen appears. The lightbar
connects to the TSIP receiver. The message Connection Established appears.
4.
Press . The External DGPS Source screen appears, showing the available corrections on the reciever. 5.
18
