104 Zone administration
The selected FA zone is deleted from the Zone Admin buffer.
Managing zoning configurations
A zone configuration is a group of zones. Zoning is enabled on a fabric by enabling a specific
configuration. You can specify members of a configuration using the following methods:
• Zone names
• QuickLoop names
• FA zone names
Figure 33 shows a sample zoning database and the relationship among the zone aliases, zones, and
zoning configuration. The database contains one zoning configuration,
myconfig
, which contains two
zones:
Zone A
and
Zone B
. The database also contains four aliases, which are members of Zone A and
Zone B. Zone A and Zone B also have additional members other than the aliases.
Figure 33 Sample zoning database
Creating a zoning configuration
Use the following procedure to create a zone configuration. After creating a zone configuration, you must
explicitly enable it for it to take effect.
To create a zone configuration:
1. Launch the Zone Admin module as described on page 95 .
Zone C onfiguration: myc onfig
W W N 5;
A lias 3
W W W 5; W W N 6; W W N7
A lias 4
Zone B
Other E lements
W W W 9
W W N 1; W W N 2; W W N 3
A lias 1
W W N 4;
A lias 2
Zone A
;
Other E lements
