9
Introduction
Display Screens
If you press the Scroll button several times, you will see the
following displays successively.
Power-On Screen When you power on the receiver, the Ashtech logo appears on
the screen. It is displayed until the receiver has completed its
auto-test (this takes about 30 seconds).
Then the General Status screen is displayed.
General Status
Screen
An example of General Status screen is shown below.
This screen displays the following information:
• : Satellite icon [1] (always displayed).
• Number of satellites tracked [2].
• Position solution status [3]:
– NONE: Position not available
– AUTO: Autonomous GPS position
– DGPS: Differential GPS position
– S DGPS: SBAS Differential GPS position
– FLOAT: Float solution
– FIXED: Fixed solution (RTK is operational)
– BASE: Receiver configured as a base.
[1]
[9] [10] [11] [12] [13]
[2] [3] [4]
[5]
[6]
[8]
[7]
