Brocade Mobility RFS7000-GR Controller CLI Reference Guide (Supporting software release 4.1.0.0-040GR and later) - Manual (Page 491)

Brocade Mobility RFS7000-GR CLI Reference Guide 477
53-1001945-01
RADIUS Configuration Commands
19
proxy
RADIUS Configuration Commands
Use this command to configure a proxy RADIUS server based on the realm/suffix.
Syntax
proxy(realm|retry-count|retry-delay)
proxy realm(nameWORD)server(IP Address)secret (0|2|WORD)
Parameters
Usage Guidelines
Only five RADIUS proxy server’s can be configured. The proxy server attempts six retries before it
times out. The retry count defines the number of times the switch transmits each RADIUS request
to the server before giving up. The timeout value defines the duration for which the switch waits for
a reply to a RADIUS request before retransmitting the request.
Example
RFS7000(config-radsrv)#proxy realm Test server 10.10.10.1 secret "Very Very
Secret !!!"
RFS7000(config-radsrv)#
RFS7000(config-radsrv)#proxy retry-count 5
RFS7000(config-radsrv)#
RFS7000(config-radsrv)#proxy retry-delay 8
RFS7000(config-radsrv)#
realm WORD Realm name is a string of up to 50 characters.
•
server (A.B.C.D) – Proxy server IP address.
•
secret (0|2|WORD) – Proxy server secret string.
•
0 – Password is specified UNENCRYPTED.
•
2 – Password is encrypted with password-encryption secret.
•
WORD – The proxy server shared secret up to 32 characters.
retry-count <3-6> Proxy server retry count value.
retry-delay <5-10> Proxy server retry delay time (in seconds).
