Brocade Mobility RFS7000-GR CLI Reference Guide
473
53-1001945-01
RADIUS Configuration Commands
19
ldap-server
Use this command to configure LDAP server parameters. It uses the existing external database in
form of an active directory with the onboard RADIUS server instead of a local database on the
switch.
Syntax
ldap-server[primary|secondary] (host
(login
(passwd-attr0 (group-attr)(group-filter)(group-membership)(net-timeout <1-10>)
Parameters
Usage Guidelines
Use the login filter and group filter values, described in the example on the following page, for all
LDAP configuration scenarios.
Use
passwd
parameter to enter the password for active directory user mentioned in bind -dn. This
will be used for initial login to the active directory.
The
passwd-attr
and
group-membership
is retained as described in the example.
primary
Primary LDAP server configuration.
secondary
Secondary LDAP server configuration.
host
LDAP server ip configuration.
•
A.B.C.D – LDAP server ip address
port
Enter the TCP/IP port number for the LDAP server acting as the data source.
login
Use the following as the login:
(sAMAccountName=%{Stripped-User-Name:-%{User-Name}})
bind-dn
Specifies the distinguished name to bind with the LDAP server.
base-dn
Specifies a distinguished name that establishes the base object for the search. The
base object is the point in the LDAP tree at which to start searching.
passwd[0|2|
Enter a valid password for the LDAP server.
•
0 – Password is specified UNENCRYPTED.
•
2 – Password is specified encrypted with password-encryption secret.
•
passwd-attr
Enter the password attribute used by the LDAP server for authentication.
The password attribute is of size 32 .
group-attr
Specifies the group attribute used by the LDAP server.
The group attribute is of size 32
group-filter
Specifies the group filters used by the LDAP server.
group-membership
Specifies the group member attribute sent to the LDAP server when authenticating
users.
The group member attributeis of size 63.
net-timeout <1-10>
Enter a timeout the system uses to terminate the connection to the RADIUS Server if
no activity is detected.
•
<1-10> – Net time out range.
