Page 89: Image capture settings, Control panel shortcuts

background image

Issue 4.3.C

IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out

EVS Broadcast Equipment

76

4.13.4 I

MAGE

C

APTURE

S

ETTINGS

These settings relate to the Grab Frame option that is to be
found on the Transport Functions pane of the Control Panel.

D

EFAULT

P

ATH FOR

C

APTURED

I

MAGES

This setting allows the operators to specify a path on which the

grabbed frames will be stored when the user clicks the Grab
Frame icon

in the Control Panel.

This path, which can be specified by each user, needs to point to
a shared folder on the TCP.IP network. The path needs to have
the following pattern:

\\MachineName\SharedFolder\.

C

APTURE

I

MAGES ON ALL

G

ANGED

R

ECORDERS

OR

L

INKED

C

LIPS

When this option is selected, the image grabbed on a clip will
also be grabbed:

• on all player channels ganged to the player channel on which

the clip is loaded.

• on all clips linked to the clip on which the image is grabbed.

4.14 CONTROL PANEL SHORTCUTS

In the IP Director main window, the menu Tools > Define
Shortcuts
in the menu bar allows the users to define shortcuts

for most of the common operations with the IP Director.

Shown in the screenshots below are all items that are available
in the Control Panel with shortcuts, the default values are
shown. These can be modified and saved by the system user if
desired.

The greyed-out shortcuts are defined as Channel Management
shortcuts and available in the Control Panel. For more
information, refer to the Shortcut section.
