OUT Zone
In this zone, the OUT point of the inserted train can be defined.
It can have one of the following values:
• unknown
• a fixed T/C value
• a value calculated based on a duration from the IN point
Unknown
The OUT point of the element is not known, it is an open end
element. The element will be played out with the defined delay
until an OUT point is entered.
T/C OUT
When the window opens, the T/C OUT field is filled with the on-
air T/C of the preview panel (if it has a value) or with the T/C of
the channel associated to the on-air panel if there is no value in
the preview pane. If there is no value in either of the previous
cases then a ‘00:00:00:00’ will be shown.
To manually define a T/C, click in the T/C OUT field and type in
a value.
To grab a value use the transport controls on the preview or on-
air channel to move to a different value and then grab the
required value in the T/C OUT field by clicking the Grab button.
Duration
To manually define a T/C, click in the Duration field and type in
a value. When the operation is validated by clicking on the OK
button, the element is inserted in the list before or after the
selected element (depending on the Insert mode in play-list
parameters in the section “Insert Mode in Play-List”, on page
169).
M
ODIFY
LIVE
OR
D
ELAY
If a live or delayed element is present in the play-list the
contextual menu changes to reflect this by showing Modify LIVE
or Delay, when this option is selected, the same window as
Insert LIVE or Delay is displayed but containing the information
for the selected element that has previously been entered.
The element can then modified and the new information validated
by clicking on the OK button or cancelled by selecting the cancel
button.
