Issue 4.3.C

IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out

EVS Broadcast Equipment

10

3. VTR Control Panel

3.1 INTRODUCTION

3.1.1 P

URPOSE

The purpose of the VTR Control Panel is to control a VTR (Video

Tape Recorder) from IP Director. It is an advanced remote
control, from within the IP Director application.

Apart from playback and record control, it also allows the
extraction of clips from a tape to the XT servers. This process
can be done with an individual “auto-edit” or multiples can be

“batch digitized”.

3.1.2 O

VERVIEW OF THE

D

ISPLAY

M

ODES

The VTR Control Panel has 3 display modes:

• transport mode
• auto-edit mode
• batch list mode

The display modes are controlled by the buttons in the top right

corner of the initial VTR Control Panel window.

Button status

Display mode

Transport mode

Auto-edit mode

Batch list mode

To select a display mode: click the corresponding block (top left
/ top right / bottom).
