IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment Issue 4.3.C
11
3.2 OPENING THE VTR CONTROL
PANEL
There are several ways of opening the VTR Control Panel:
• from Channel Explorer
• from the IP Director main toolbar
The procedures are described in detail on the following pages.
3.2.1 H
OW TO
O
PEN THE
VTR C
ONTROL
P
ANEL
F
ROM
C
HANNEL
E
XPLORER
To open the VTR Control Panel from Channel Explorer, proceed
as follows:
1. Click Channel Explorer on the application toolbar.
2. In the Channel Explorer, browse to the VTR you wish to
control.
3. Double-click the VTR, in this example DVC PRO 50.
OR
Right-click the VTR and select Open VTR Control
Panel.
4. The VTR panel is opened and linked to DVC PRO 50.
