Issue 4.3.C IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment
124
XT C
HANNEL
O
N
-S
CREEN
D
ISPLAY
If the play-list is cued ready for play out on the output of an XT
server channel the channel’s OSD display will show all relevant
information
PL11/03: PL is always displayed. 11/03 corresponds to
the LSM ID of the play-list loaded on the
channel. PL11/03 is displayed in RED if the
channel is on-air.
Nxt Brk
00:17:13: ‘Nxt Brk’ is always displayed. ‘00:17:13’
corresponds to the remaining time till the next
break in the play-list.
A key is displayed if the channel is locked. No character is
displayed if the channel is not locked.
Audio meters.
• With 8 audio tracks : all 4 lines are used.
• With 4 audio tracks : only lines 8 and 9 are used.
PL11/03 Nxt Brk 00:17:13
³
█ █ █ █
█ █ █ █
█ █ █ █
P L 1 1 / 0 3 Nxt Brk 00:07:13
³
█ █ █ █
█ █ █ █
█ █ █ █
